HICLOVER TS10 (PLC) Mobile Incineration System

Product Overview: HICLOVER TS10 (PLC) Mobile Incineration System

1. Technical Configuration

The HICLOVER TS10 (PLC) is a mobile trailer-mounted incinerator designed for small-scale, field-based waste disposal. It integrates a wet scrubber (double spray tower) and a defogging tower for efficient flue-gas cleaning and visible-smoke reduction.
Key system components:

Primary Combustion Chamber: 120 L (35 × 60 × 60 cm) for direct waste loading and ignition

Secondary Combustion Chamber: 60 L (35 × 60 × 60 cm) for complete smoke and gas oxidation

Loading Door: 50 × 50 cm, top-loading configuration

Fuel Options: Diesel or LPG (ideal for field use)

Burners: Two Riello diesel or gas burners

Control System: Full PLC automation with digital monitoring and alarms

Trailer Type: 2 × 2 four-wheel design, towable by pickup or off-road vehicle

Power Supply: Portable diesel or gasoline generator

Chimney: 3 m height, detachable design

Wet Scrubber: Built-in water tank, optional external tank for extended operation

Automation and Safety Features

Automatic process control and temperature regulation

Interlocked loading door (burners shut off if door forced open)

Visual process tracking and time-based progress display

Energy-saving operation with auto-cooling sequence

High-temperature protection and fault alarms

System self-test mode for commissioning or maintenance

2. Application Scenarios

The TS10 Mobile Incinerator is engineered for remote and temporary waste-management operations where stable infrastructure is unavailable. Its compact size, modular design, and trailer mobility make it ideal for:

Medical missions and field hospitals in rural or emergency zones

Refugee and humanitarian camps under UN or NGO operations

Military bases, oil-field, or mining camps requiring onsite waste destruction

Small clinics, laboratories, or veterinary stations handling infectious or animal waste

Disaster-response operations where rapid deployment and self-contained utilities are required

Equipped with a dual-stage combustion system and wet-scrubber exhaust treatment, the TS10 ensures compliance with international environmental standards such as EU IED, WHO guidelines, and GB 18484-2020 for medical waste incineration.

This model represents a complete field-ready waste-treatment solution―self-powered, easily transported, and controlled through intelligent automation to achieve clean, safe, and efficient combustion wherever needed.
